| DN |
OD |
Εύρος OD |
Ίντσα |
Εύρος Ροής |
| DN4 |
OD9.53 |
95mm-10.5mm |
1/8" |
0,003~0,142 m³/h
0,047~2,374 l/min
0,013~0,627 gal/min |
| DN8 |
OD12.7 |
12,4mm-13,1mm |
1/4" |
0,011~0,570 m³/h
0,190~9,496 l/min
0,050~2,509 gal/min |
| DN10 |
OD15 |
14,5mm-15,4mm |
3/8" |
0,026~1,282 m³/h
0,427~21,366 l/min
0,113~5,644 gal/min |
| DN15 |
OD20 |
16,5mm-23,0mm |
1/2" |
0,046~2,279 m³/h
0,760~37,984 l/min
0,201~10,034 gal/min |
| DN20 |
OD25 |
25,0mm-30,0mm |
3/4" |
0,103~5,128 m³/h
1,709~85,464 l/min
0,452~22,577 gal/min |
| DN25 |
OD32 |
32,0mm-35,0mm |
1" |
0,182~9,116 m³/h
3,039~151,935 l/min
0,803~40,137 gal/min |
| DN32 |
OD40 |
38,0mm-45,0mm |
1-1/4" |
0,285~14,244 m³/h
4,748~237,399 l/min
1,254~62,714 gal/min |
| DN40 |
OD50 |
48,0mm-54,0mm |
1-1/2" |
0,410~20,511 m³/h
6,837~341,854 l/min
1,806~90,309 gal/min |
| DN50 |
OD63 |
58,0mm-64,0mm |
2" |
0,729~36,464 m³/h
12,155~607,741 l/min
3,211~160,549 gal/min |
| DN65 |
OD75 |
72,0mm-78,0mm |
2-1/2" |
1,140~56,976 m³/h
18,992~949,595 l/min
5,017~250,857 gal/min |
| DN80 |
OD90 |
80,0mm-92,0mm |
3" |
1,641~82,045 m³/h
27,348~1367,417 l/min
7,225~361,234 gal/min |
| DN100 |
OD110 |
108,0mm-116,0mm |
4" |
2,917~145,858 m³/h
48,619~2430,963 l/min
12,844~642,194 gal/min |
| DN125 |
OD140 |
132,0mm-142,0mm |
5" |
4,558~227,903 m³/h
75,968~3798,380 l/min
20,069~1003,429 gal/min |
| DN200 |
OD220 |
218,0mm-228,0mm |
8" |
11,669~583,431 m³/h
194,477~9723,852 l/min
51,376~2568,778 gal/min |
